| Category |
Specification |
| Motor System |
|
| Motor Type |
PMSM (Permanent Magnet Synchronous Motor) |
| Rated Power |
6 kW |
| Max Power |
13.5 kW |
| Encoder Type |
High resolution magnetic encoder |
| Protection Level |
IP67 |
| Power |
|
| Battery Cell |
NCM lithium battery / HN-EM7450NLP001 / Semi-solid state / High security |
| Battery Pack |
74V, 50 Ah / BMS / Anti-shock / IP67 protection level |
| Battery Life |
Charging cycle ≥ 1500 or 26 months |
| Charger |
74V/15A (supports 3C fast charge) |
| Charging Time |
≤ 3 hours |
| Controller |
|
| Controller Type |
FOC (Field-Oriented Control) |
| Electromagnetic Voltage |
74V |
| Protection Level |
IP67 |
| Low Voltage Parts |
|
| Meter |
TFT screen, 3.2 inches, IP67 waterproof |
| Headlight |
Alufer shell CNC, anodic oxidation, High brightness triple lens |
| Electric Door Lock |
Mechanical |
| Brake System |
|
| Front Brake |
Hand brake, disc Φ240, 4-piston caliper, "TSK", DOT oil tube |
| Rear Brake |
Hand brake, disc Φ240, single piston, "TSK", DOT oil tube |
| Drive System |
|
| Front Suspension |
"FAST", Internal tube Φ38, travel length 240, adjustable compression and recovery damping, External tube CNC, Foot down 6061 forging |
| Rear Suspension |
"FAST", travel length 83, top support 6061 forging, lower fork CNC, adjustable compression and recovery damping |
| Front/Rear Tyre |
80/100-19, 80/100-19, "CST" |
| Front/Rear Rim |
1.6×19 (7075), 1.6×19 (7075), "UNISON" |
| Main/Side Frame |
Welding combination, left and right integrated 6061 forging, baking varnish |
| Transmission |
|
| Chain |
428HHD-114 |
| Gearbox |
Two-stage deceleration, speed ratio 2.467 |
| Front/Rear Chain Sprocket |
428-13T (front), 428-50T (rear) |
| Energy Regeneration |
Manual adjustment levels I, II, III, IV |
| General Info |
|
| LWH (mm) |
1977 × 807 × 1155 |
| Wheelbase (mm) |
1345 |
| Net Weight (kg) |
≤ 85 kg (with battery) |
| Max Speed (km/h) |
≥ 100 km/h |
| Max Torque (Nm) |
480 Nm @ 500 rpm |
| 40 km/h Constant Speed Range (km) |
140 km |
| Work Condition Mileage (km) |
117 km |
| 0-50 km/h Acceleration Time (s) |
≤ 2.2 seconds |
| Max Ground Clearance (mm) |
318 mm |
| Seat Height (mm) |
890 mm |
| Loading Quantities |
147 units per 40' container |
